Storage

Constructed with corrugated steel sheet panels type FeE 350 G with Sendzimir Z-350 galvanization, 350 gr / m2 which guarantees long resistance to atmospheric agents. The structure is externally reinforced by uprights in press-bent sheet metal of variable thickness and sections. The assembly of the plates and uprights is done with high mechanical strength bolts treated with the Dacromet process against corrosion. The infiltration of water into the joints of the sheets is avoided thanks to the interposition of plastic joints which maintain their characteristics unchanged over time. The roof is made up of trapezoidal elements in galvanized sheet steel with a reinforcing binding to withstand the loads due to snow, transport systems and inspection walkways. The roof is made with an inclination of 25 ° and 30 ° and is raised by the cylinder by approx. 40 mm. to allow the circulation of air by convection and reduce the condensation phenomenon. The silo is supplied with the following accessories: hatch on the roof for checking the ensiled cereal; a manhole positioned on the second ferrule which allows maintenance personnel to enter the empty silo; a circumferential anti-sparrow net to be mounted between the roof and the last ferrule.

Made of unsaturated polyester resin reinforced with glass fibers, they are used for the storage of loose materials made up of mixtures of feed or cereals in general. The silos are supplied complete with support legs in hot-galvanized steel, bolted to the silos itself, ground-level lid opener, translucent level strip, auger door and ladder with protections.

Made with capacities from 1 to 100 cubic meters, the structures can be built in galvanized carbon steel or in ASI 304 stainless steel.
Extraction systems suitable for the stored product.
